The AKG P120 is a 2/3-inch diaphragm true condenser microphone that offers solidly built quality, outstanding performance and excellent value. The low-mass diaphragm delivers a clear sound with accurate sonic detail for vocals, speech and instrument recording in project studios and for home recording.

KEY SPECIFICATIONS

Capsule 2/3" condenser

Polar Pattern cardioid

Frequency Response 20 Hz to 20 kHz (see frequency response trace)

Sensitivity 24 mV/Pa (-32,5 dBV)

Max. SPL for 0.5 % THD 130/150 dB (0/-20 dB pad)

Equivalent Noise Level To IEC 60286-4 19 dB (A)

Signal To Noise 75 dB (A) re 1Pa

Preattenuation Pad -20 dB

Bass Cut Filter 300 Hz, 6 dB/octave

Electrical Impedance = 200 ohms

Recommended Load Impedance = 1000 ohms

Connector 3-pin XLR (pin 2 hot)

Phantom Powering 48 V ± 4 V to IEC 61938

Current Consumption = 3 mA

Temperature Range -10 °C to +60 °C (14 °F - 140 °F)

Diameter 54 mm (2.13 in.)

Length 165 mm (6.5 in.)

Net Weight (Mic Only) 455 g (16 oz.)
