Diamond J-Drive MK3 Overdrive/Boost Pedal

Diamond

$389.00

or 6 weekly payments from $64.83 Group Created with Sketch. learn more

The Mk3 evolution of the J-Drive integrates even more functionality and tonal variations into the combined drive and clean boost concept.



In the clean boost section, the Mk3 has an independently switchable clean boost consisting of a Vishay JFET and BJT clean boost.



Borrowing from the limited edition J-Drive TR, Diamond also added a cool transformer output stage to the overdrive section; it has a wonderful smoothing effect on the upper mids and highs, placing an inductive source impedance at the amp's input as a guitar's pickup would (but at a lower output impedance so it works great into other pedals as well as amps).



Their 'Close Asymmetry' overdrive circuit utilizes a Schottky barrier diode for smooth asymmetrical clipping, which combined with the transformer output gives a liquid-smooth sustain with punch. The 'Warmth' control offers a unique tonal control adding low-end gain while simultaneously cutting top-end - perfect for warming up a bright amp or guitar. They've also added a toggle switchable high-frequency shelf filter to add extra 'bite' when needed.

- true bypass signal path for both the clean boost and drive sections

- discrete clean boost circuit with JFET input/BJT amplifier

- premium audio components, including 2% polypropylene capacitors, 1% metal film resistors and a Burr-Brown OPA2134 opamp

- post-volume control overdrive transformer output stage that smooths upper mids and highs

- 'Close Asymmetry' Schottky diode clipping circuit

- switchable highpass shelf filter for additional 'bite', implemented without additional active components

- battery or standard negative tip 9V DC adapter operation

SKU: 22611 TAG: Distortion Overdrive and Fuzz
