Joyo JP-05 Rechargable Power Supply - 8 Inputs



or 6 weekly payments from $24.83 Group Created with Sketch. learn more

The JOYO JP 05 Power Supply features, 8 DC centre negative outputs, 4 x 100ma 9v, 3 x 500ma 9v and 1 switchable to 9v, 12v or 18v at 100ma. The power supply also features a 5v USB, perfect for powering USB devices & charging your phone.


To top off the feature list, it has a built-in 7.4v/4400 mAh rechargeable lithium battery pack that charges fully in 3-4 hours making sure that you are never without power.


Each output of the power supply features independent filters, output overload & short-circuit protection protecting your pedals and filtering out any unwanted noises. The power supply has a 4 stage battery indicator. You can use the supply when it is in charging mode powered by the supplied JOYO 9v 2000ma adaptor. The level of battery power will be indicated by the LED display on the top of the pedal (0% - Red flashing (charge it up!), 0-30% - Red, 30-60% - Yellow, 60-100% - Green) flashing above to show status. 8 LEDs can light up your board in a bright cool blue glow. An option to turn the LED lights on and off is readily available. If you are using the supply as a portable unit, it would make sense to turn them off.


This makes a pretty versatile power supply, useful for guitar effects and other electronic instruments. The JOYO JP-05 is even supplied with a polarity converter for instruments/effects that require a centre positive supply.


The Tech Features:

Brand: Joyo

Model: JP05

Outputs: Isolated Centre Negative DC 9V

3 x 500 mA

4 x 100 mA

1 x switchable 9, 12 or 18v at 100mA

1 x standard USB output (5V enables cell phone, IPad and other portable devices)

Dimensions: 14.6cm x 6.5cm x 3.5cm


USB Port

7.4V/4400 mAh built-in lithium battery (charging time 3-4 hrs)

 Isolated Short Circuit Protection, Battery Indicator, LED Lights

DC Jack Measurements:- Outer - 5.5mm , Inner - 2.1mm


Included Accessories:- 8 x DC patch cables, Reversed Polarity Cable

SKU: 22347 TAG: Power Supply
