dB Technologies KL12 2-Way Active Loudspeaker

KL series aims to enhance usability and versatility in dBTechnologies’ 2-way active speaker series: combining efficiency with professional sound performance, KL systems feature Bluetooth® connection, 3 INPUT channels, impressive SPLs and a powerful DSP where linear phase FIR filters ensure the most accurate sound reproduction.

Technical Data
Speaker Type:   2-Way Active Speaker

Acoustical Data
Frequency Response [-10dB]:   52 - 18.000 Hz
Max SPL:   127 dB
HF:   1" CD, 1.35"v.c
LF:   12", 2.5" v.c.
Dispersion:   90°x60°
Crossover Frequency:   1800 Hz (24 dB/oct.)

Amplifier:
Amp Technology:  Class D(LF)+Class AB (HF)
Power Peak (LF+HF):  800 W

Processor:
Controls:   1xVolume, 1xslide switch mic/line
Indicators:   power on/signal/limiter LEDs
Controller:   DSP 20/56 bit
AD/DA Converter:   24 bit/ 48 Hz
Systems Presets:   Playback, Flat, Bass Boost, Wedge
Limiter:   Peak, RMS, Thermal
Advanced DSP Functions:   Linear Phase FIR Filters

Input
Signal Input:   1x Combo(XLR/Jack)
Mic/Line
1xXLR/TRS
Bluetooth Input:   1xBluetooth receiver
SIGNAL Output:   1xXLR Male (LINK/MIX
